Image similar
Image similar
Phoenix Contact Socket housing PCB IMC Total number of pins 3 Contact spacing: 3.81 mm 1862580 50 pc(s)
EAN:
Part number:
Item no:
Product type
Socket housing PCB
Connector type
Socket, horizontal mount
No. of rows
1
Series
IMC
CS
3.81 mm
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 1.31 / piece)
€ 65.54
plus VAT.
14-day return policy included
Highlights & Details
Base strip IMC 1,5/ 3-G-3,81
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 3
Technical specifications
- Product type
Socket housing PCB
- Connector type
Socket, horizontal mount
- No. of rows
1
- Connector system
wire-to-board
- Series
IMC
- Features
for touch-safe outputs
- CS
3.81 mm
- Pins per row
3
- Total number of pins
3
- Width
14.50 mm
- Nominal current
8 A
- Nominal current - rounded value
8 A
- Content
50 pc(s)
- Dim
(L x W x H) 10.25 x 14.50 x 12.22 mm
- Connection
Print
- Manufacturer part #
1862580
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Nominal voltage
160 V
- Height
12.22 mm
- Length
10.25 mm
- Connector orientation
Parallel (to the PCB)
- Type
IMC 1,5/ 3-G-3,81
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 566801 Phoenix Contact Socket housing PCB IMC Total number of pins 3 Contact spacing: 3.81 mm 1862580 50 pc(s)
User & Safety Instructions
User & Safety Instructions 566801 Phoenix Contact Socket housing PCB IMC Total number of pins 3 Contact spacing: 3.81 mm 1862580 50 pc(s)
Description
Header, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 3, Pitch: 3.81 mm, Color: green, Contact surface: Tin, Assembly: Soldering
