Phoenix Contact Socket housing cable GMSTB Total number of pins 4 Contact spacing: 7.62 mm 1714294 50 pc(s)
EAN:
Part number:
Item no:
Product type
Socket housing cable
Connector type
Socket, straight
No. of rows
1
Series
GMSTB
CS
7.62 mm
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 4.20 / piece)
€ 210.08
plus VAT.
Highlights & Details
Plug GMSTB 2,5 HCV/ 4-ST-7,62
- Content: 50 pc(s)
- No. of rows: 1
- Total number of pins: 4
Technical specifications
- Product type
Socket housing cable
- Connector type
Socket, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
GMSTB
- Features
+ extractor sleeve
- CS
7.62 mm
- Pins per row
4
- Total number of pins
4
- Width
30.26 mm
- Nominal current
16 A
- Nominal current - rounded value
16 A
- Content
50 pc(s)
- AWG max.
12
- AWG (min.)
24
- Stripping length (max.)
8.00 mm
- Dim
(L x W x H) 17.50 x 30.26 x 21.00 mm
- Connection
Screw terminal
Plug
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1714294
- Industrial packaging
Yes
- Contact material
Tin plated
- Connector contact surface
Tin plated
- Nominal voltage
1000 V
- Height
21.00 mm
- Length
17.50 mm
- max. cross section
2.5 mm²
- Min. cross section
0.2 mm²
- Type
GMSTB 2,5 HCV/ 4-ST-7,62
Documents & Downloads
Datasheet
Datasheet 195868 Phoenix Contact Socket housing cable GMSTB Total number of pins 4 Contact spacing: 7.62 mm 1714294 50 pc(s)
User & Safety Instructions
User & Safety Instructions 195868 Phoenix Contact Socket housing cable GMSTB Total number of pins 4 Contact spacing: 7.62 mm 1714294 50 pc(s)
Description
Plug component, Nominal current: 16 A, Rated voltage (III/2): 1000 V, Number of positions: 4, Pitch: 7.62 mm, Connection method: Screw connection, Color: green, Contact surface: Tin
