Phoenix Contact 3076039 PG terminal 8.2 mm Screws Grey 50 pc(s)
EAN:
Part number:
Item no:
Product type
PG terminal
Connection
Screws
Cross section (flexible) (max.)
10 mm²
Cross section (inflexible) (max.)
10 mm²
Content
50 pc(s)
Number (Package size 50 pc(s))
Total (€ 4.62 / piece)
€ 231.09
plus VAT.
14-day return policy included
Technical specifications
- Product type
PG terminal
- Connection
Screws
- Cross section (flexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
10 mm²
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (inflexible) (max.)
10 mm²
- Clamp width
8.2 mm
- Factory colour
Grey
- Nominal voltage
400 V
- Manufacturer part #
3076039
- Content
50 pc(s)
- Type
UTI 6-PE/L/NT
- Height
51.5 mm
- Length
95 mm
- Weight
20 g
- Flammability rating
V0
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1831009 Phoenix Contact 3076039 PG terminal 8.2 mm Screws Grey 50 pc(s)
Description
The terminal is characterised by its especially low design and is suitable for the wiring in installation flat distributors. Due to the asymmetrical arrangement of the terminals on the rail, you can set the neutral conductor busbar andean terminals.
