Picotronic Laser module Line Blue 1 mW LE 405-1-3 (14x45) 90 DEG F 150
EAN:
Part number:
Item no:
Product type
Laser module
Emission characteristics
Line
Wavelength
405 nm
Power
1 mW
Laser category
1
Datasheet (PDF)
Number
Total (€ 239.50 / piece)
€ 239.50
plus VAT.
Only 5 Piece(s) available
Highlights & Details
Laser module line
- Blue
- Laser category: 1
- Emission characteristics: Line
Technical specifications
- Connection cable 100 mm
- Product type
Laser module
- Type
LE 405-1-3 (14x45) 90 DEG F 150
- Emission characteristics
Line
- Focus properties
150 mm fixed-focus
- Factory colour
Blue
- Wavelength
405 nm
1 mW
- Laser category
1
- Angular aperture
90°
- Beam divergence
0.6 mrad
- Clearance
0.15 m
- Operating voltage
3 V DC
- Operating current
60 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+60 °C
- Min. temperature
-10 °C
Documents & Downloads
Datasheet
Datasheet 1695952 Picotronic Laser module Line Blue 1 mW LE 405-1-3 (14x45) 90 DEG F 150
User & Safety Instructions
User & Safety Instructions 1695952 Picotronic Laser module Line Blue 1 mW LE 405-1-3 (14x45) 90 DEG F 150
Information
Information 1695952 Picotronic Laser module Line Blue 1 mW LE 405-1-3 (14x45) 90 DEG F 150
Conformity certificate
Conformity certificate 1695952 Picotronic Laser module Line Blue 1 mW LE 405-1-3 (14x45) 90 DEG F 150
Description
Hints
Class 1: laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
