Picotronic Laser module Line Green 10 mW LD 532-10-24 (20 x 80)-PL-C1500-G
EAN:
Part number:
Item no:
Product type
Laser module
Emission characteristics
Line
Wavelength
532 nm
Power
10 mW
Laser category
1
Datasheet (PDF)
Number
Total (€ 466.39 / piece)
€ 466.39
plus VAT.
14-day return policy included
Highlights & Details
Laser module line
- Green
- Laser category: 1
- Emission characteristics: Line
Technical specifications
- Connection cable 1500 mm
- Product type
Laser module
- Type
LD 532-10-24 (20 x 80)-PL-C1500-G
- Emission characteristics
Line
- Focus properties
3000 mm fixed-focus
- Factory colour
Green
- Wavelength
532 nm
10 mW
- Laser category
1
- Angular aperture
90°
- Beam divergence
0.5 mrad
- Clearance
3 m
- Operating voltage
24 V DC
- Operating current
60 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+30 °C
- Min. temperature
-15 °C
Documents & Downloads
Datasheet
Datasheet 1695863 Picotronic Laser module Line Green 10 mW LD 532-10-24 (20 x 80)-PL-C1500-G
User & Safety Instructions
User & Safety Instructions 1695863 Picotronic Laser module Line Green 10 mW LD 532-10-24 (20 x 80)-PL-C1500-G
Information
Information 1695863 Picotronic Laser module Line Green 10 mW LD 532-10-24 (20 x 80)-PL-C1500-G
Conformity certificate
Conformity certificate 1695863 Picotronic Laser module Line Green 10 mW LD 532-10-24 (20 x 80)-PL-C1500-G
Description
Hints
Class 1: laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
