Picotronic Laser module Line Red 16 mW LC 650-16-24-F (14 x 62) 30
EAN:
Part number:
Item no:
Product type
Laser module
Emission characteristics
Line
Wavelength
650 nm
Power
16 mW
Laser category
2M
Datasheet (PDF)
Number
Total (€ 239.50 / piece)
€ 239.50
plus VAT.
14-day return policy included
Highlights & Details
Laser module line
- Red
- Laser category: 2M
- Emission characteristics: Line
Technical specifications
- Connection cable 100 mm
- Product type
Laser module
- Type
LC 650-16-24-F (14 x 62) 30
- Emission characteristics
Line
- Focus properties
Selectable focus
- Factory colour
Red
- Wavelength
650 nm
16 mW
- Laser category
2M
- Angular aperture
30°
- Beam divergence
0.4 mrad
- Clearance
4 m
- Operating voltage
24 V DC
- Operating current
15 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+50 °C
- Min. temperature
-20 °C
Documents & Downloads
Datasheet
Datasheet 1695842 Picotronic Laser module Line Red 16 mW LC 650-16-24-F (14 x 62) 30
User & Safety Instructions
User & Safety Instructions 1695842 Picotronic Laser module Line Red 16 mW LC 650-16-24-F (14 x 62) 30
Information
Information 1695842 Picotronic Laser module Line Red 16 mW LC 650-16-24-F (14 x 62) 30
Conformity certificate
Conformity certificate 1695842 Picotronic Laser module Line Red 16 mW LC 650-16-24-F (14 x 62) 30
Description
Hints
Class 2M: laser radiation! Observe safety instructions! Never look into the beam (may damage your retina).
