Pin insert 09120062666 HARTING Content: 1 pc(s) Pin inset
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Pin inset
Number of pins
4
Type
09120062666
Manufacturer part #
09120062666
Datasheet (PDF)
Number
Total (€ 50.41 / piece)
€ 50.41
plus VAT.
Only 5 Piece(s) available
Highlights & Details
Pin insert
Our service for you
Technical specifications
- Net weight: 43.8 g
- Size: Han-Compact
- Rated current: 40 A
- Number of contacts: 4
- conductor cross-section: 4 mm² - 10 mm²
- Gender: Pin
- Plug-in cycles: ≥ 500
- Tightening torque: 1.8 Nm
- Rated voltage Conductor-earth: 400 V
- Rated voltage Conductor-conductor: 690 V
- Rated voltage: 6 kV
- Contact surface: Silver plated
- Forward resistance: ≤ 0.3 mΩ
- Pollution degree: 3
- additional contacts: + 2 additional control contacts
- Packaging type
Piece
- Type
09120062666
- Product type
Pin inset
- Manufacturer part #
09120062666
- Factory colour
Pebble grey (RAL 7032)
- Number of pins
4
- Connection
Axial screw terminal
- Total no. of pins
4 + PE
- Content
1 pc(s)
- Material
Polycarbonate (PC)
Copper alloy
- Max. temperature
+125 °C
- Leading contact (PE)
Yes
