Posital Fraba Incremental Rotary encoder 1 pc(s) UCM-IPT00-02048-F10W-HFZ Clamping flange Piece
Part number:
Item no:
Packaging type
Piece
Product type
Rotary encoder
Model
Incremental
Min. operating voltage
4.75 V DC
Max. operating voltage
30 V DC
Technical specifications
- Packaging type
Piece
- Product type
Rotary encoder
- Type
UCM-IPT00-02048-F10W-HFZ
- Model
Incremental
- Min. operating voltage
4.75 V DC
- Max. operating voltage
30 V DC
- Operating voltage
4.75 - 30 V DC
- Connector
Connector cap
- Orientation (connectors)
Radial
- Features
Incl. 2x filler plug
- Steps per cycle
02048
- Impulses per cycle (max.)
2048
- Sleeve type
Clamping flange
- Shaft type
Solid shaft
Flat on one end
- Shaft depth
20 mm
- Shaft Ø
10 mm
- Material (sleeve)
Stainless steel V4A
- Min. temperature
-40 °C
- Max. temperature
70 °C
IP66/IP67
- RoHS-compliant
Yes
- Content
1 pc(s)
