Power meter 182700700013X Uni-T UTE9806+
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
UNI-T POWER METER UTE9806 +
Technical specifications
- Measurement of Real effective value (True RMS)
- Limit alarm system (upper/lower limit)
- Average function
- Adjustable data update rate
- RS-232 & RS-485 interfaces for SCPI/Modbus-connection
- Basic accuracy: ± (0.4 % v. + 0.1 % range + 1 digit)
- Resolution voltage 0.01 V
- Current resolution 0.01 mA
- Power resolution 1 mW
- MEASUREMENT PARAMETERS V, A, W, VA, PF, VHS, AHZ, Vpk, pk
- Form factor: ½ 2U (19-inch rack-enabled)
- Supply voltage AC 100 V – 240 V, 50/60 Hz
- Product type
Power meter
- Acoustic signal
Yes
- Display
LCD
- Optical display
Yes
- Test sockets
Screw terminals
- Dim
(W x H x D) 214 x 88 x 340 mm
Manufacturer's standards (no certificate)
- Weight
3.2 kg
- Features
Data export mode
- Reading category
CAT II 600 V
- Width
214 mm
- Height
88 mm
- Depth
340 mm
- Type
UTE9806+
Documents & Downloads
Datasheet
Datasheet 3812396 Power meter 182700700013X Uni-T UTE9806+
User & Safety Instructions
User & Safety Instructions 3812396 Power meter 182700700013X Uni-T UTE9806+
Description
The UTE9800+ series is a cost-effective, portable and intelligent meter for electrical parameters. It is a multi-functional meter that integrates voltage, current, power, power factor and frequency. With an excellent price-performance ratio it is often used in the fields of production, measurement, quality assurance and scientific research.
This text is machine translated.
This text is machine translated.
Features
- Voltage range 0.5 V ~ 600 V
- Current range 0.05 mA ~ 10.0 A
- Frequency range 40 Hz - 400 Hz
- Accuracy ± (0.4% reading + 0.1 range + 1 digit)
- Measuring mode AC
- RS-232/RS-485 connectivity
- Size: ½ 2HE
- Display VA-LCD
Scope of delivery
- UTE9806+ x 1
- Power cable x 1
- RS232 Communication Line x 1
Hints
More models
- UTE9802+: 3.0 V ~ 600 V voltage range, 0.5 mA ~ 20.0 A current range, 40 Hz ~ 400 Hz (DC) frequency range, AC/DC/AC+DC measuring mode
- UTE9811+: 3.0 V ~ 600 V voltage range, 5 mA ~ 20.0 A current range, 40 Hz ~ 70 Hz frequency range, AC measuring mode
