Poynting A-OMNI-0121-V3 network antenna Omni-directional antenna SMA 6 dBi

Highlights & Details

Covers the GSM 900, GSM 1800/UMTS and LTE frequency bands
Increased connection stability
Machine-to-Machine (M2M) capabilities
Continuously high amplification over a very wide frequency range
Popular with installers because of its versatile base station
Anti-vandalism and waterproof housing (IP 65)"

Technical specifications

1.71 - 2.7 GHz
WLAN standards 802.11g
Cable type HDF-195

Product type: LTE antenna

Gain: 6 dBi

Type: Monopole antenna

Antenna socket: SMA socket

Weight: 570 g

Polarisation: Linear
Vertical

Height: 553 mm

Cable length: 8 m

Factory colour: White

(Ø): 5 cm

Impedance: 50 Ω

: IP65

Keyboard layout: German, QWERTZ

Material (details): Acrylonitrile butadiene styrene (ABS)

UKCA: yes

Operating temperature (T-T): -40 - 80 °C

Storage relative humidity (H-H): 5 - 95 %

Quantity per pack: 1 Stück(e)

Survival wind speed: 160 km/h

Gain: 6 dBi

Power handling: 10 W

Operating relative humidity (H-H): 0 - 98 %

Waterproof: yes

Storage temperature (T-T): -40 - 80 °C

Package weight: 720 g

Documents & Downloads

Datasheet

Datasheet 3790024 Poynting OMNI-121 A-OMNI-0121-V3 LTE antenna 6 dBi

User & Safety Instructions

User & Safety Instructions 3790024 Poynting OMNI-121 A-OMNI-0121-V3 LTE antenna 6 dBi

Description

Omni-directional broadband LTE antenna
Medium gain omnidirectional antenna for GSM, UMTS and LTE networks
This medium gain omnidirectional antenna covers the GSM 900, GSM 1800, UMTS and LTE frequency bands and provides reliable connectivity for various applications. This antenna is light and easy to install and offers an economical solution with the accompanying 5 m cable for flexible use. Its versatile base station features make it a popular choice for installers, while its robust performance supports Machine-to-Machine (M2M) applications that communicate over GSM networks.

Broadband frequency coverage supports GSM 900, GSM 1800, UMTS and LTE bands for seamless connectivity.
Reliable signal reception: Provides medium gain for improved performance in urban, suburban and remote areas.
Easy to install: Light design with pre-installed 5m cab file for quick and flexible deployment.
Versatile base station compatibility: Ideal for network installations that require full coverage.
Optimized for M2M applications: Suitable for machine-to-machine communication (M2M) with GPRS, EDGE, 3G, HSPA and LTE technologies.
Cost-effective connectivity solution: Provides stable signal reception at an affordable price.

This antenna is an excellent choice for installers and companies who need a reliable, easy-to-install solution for GSM, UMTS and LTE connectivity that ensures strong and stable communication across multiple applications.
