Poynting XPOL-1-5G A-XPOL-0001-V2-21 LTE antenna 4 dBi
EAN:
Part number:
Item no:
Poynting XPOL-1-5G network-antenna Omni-directional antenna SMA 4 dBi
Highlights & Details
- Exceptional performance over major 4G/5G bands
- High gain for the antenna size
- Broadband 2x2 or 4x4 MIMO 4G/5G antenna
- Downward compatible 2G/3G/4G/LTE/5G-antenna
- Weather, dust and vandal-proof housing (IP 65)
Technical specifications
- 0,617 - 3.4 GHz
- Cable type HDF-195
- Product type
LTE antenna
- Gain
4 dBi
- Antenna socket
SMA plug
- Weight
950 g
- Width
157 mm
- Height
247 mm
- Cable length
5 m
- Factory colour
White
- Depth
88 mm
- Impedance
50 Ω
IP65
- UKCA
yes
- Operating temperature (T-T)
-40 - 80 °C
- Ultraviolet (UV) resistant
yes
- Quantity per pack
1 Stück(e)
- Survival wind speed
250 km/h
- Power handling
10 W
- Operating relative humidity (H-H)
5 - 95 %
- Package weight
1.05 kg
Documents & Downloads
Datasheet
Datasheet 3789998 Poynting XPOL-1-5G A-XPOL-0001-V2-21 LTE antenna 4 dBi
User & Safety Instructions
User & Safety Instructions 3789998 Poynting XPOL-1-5G A-XPOL-0001-V2-21 LTE antenna 4 dBi
Description
The XPOL-1-5G is POYNTINGS second generation of the popular cross-polarized (XPOL) 2×2 MIMO antenna (V2). A 4×4 MIMO variant is now available for user-specific requirements. The antenna was completely newly developed and has a new housing and improved antenna technology, which improves the power over several frequency bands.
