Poynting XPOL-2-5G A-XPOL-0002-V3-02 LTE antenna 11 dBi
EAN:
Part number:
Item no:
Poynting A-XPOL-0002-V3-02 network antenna directional antenna N-type 11 dBi
Highlights & Details
- New advanced metamaterial technology
- Exceptional performance over major 4G/5G bands
- High gain for the antenna size
- Broadband 2x2 MIMO-4G/5G antenna
- Downward compatible 2G/3G/4G/LTE/5G-antenna
- Two cross-polarized antennas in one housing for optimum LTE performance
- IP65 weather-/dust- and vandal-proof casing.
Technical specifications
- 0,698-0,690, 1,710-2.7, 3.4 - 3.8 GHz
- Product type
LTE antenna
- Gain
11 dBi
- Antenna socket
N socket
- Weight
1.55 kg
- Cable length
0 cm
- Factory colour
White
IP65
- Keyboard layout
German, QWERTZ
- UKCA
yes
- Operating temperature (T-T)
-40 - 80 °C
- Quantity per pack
1 Stück(e)
- Package weight
1.86 kg
Documents & Downloads
Datasheet
Datasheet 3789999 Poynting XPOL-2-5G A-XPOL-0002-V3-02 LTE antenna 11 dBi
User & Safety Instructions
User & Safety Instructions 3789999 Poynting XPOL-2-5G A-XPOL-0002-V3-02 LTE antenna 11 dBi
Description
The XPOL 2-5G is POYNTINGS third generation (V3) of the popular cross-polarized (XPOL) 2×2 MIMO antenna. While the housing retains the known appearance of the second generation (V2), the interior design was completely revised with the help of advanced meta-material technology. The use of artificial magnetic conductors (AMC) and a patented beam configuration significantly increase bandwidth and amplification.
