Technical drawing of a cylindrical object, length 23.7 mm with three diameters: 1.24 mm, 1.68 mm, 1.83 mm.

Stroke drawing/circuit diagram

Technical drawing of a cylindrical object, length 23.7 mm with three diameters: 1.24 mm, 1.68 mm, 1.83 mm.

Diagram of an electrical fuse in top-down view. The fuse is cylindrical with a central conductive element represented by lines.

1/2

Stroke drawing/circuit diagram

PTR Hartmann

Unavailable

Show alternatives

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Total (€ 0.77 / piece)

€ 0.77

plus VAT.

Report legal concerns

Technical specifications

Continuity Resistance: ≤ 30 mΩ

Nominal current: 3 A

Nominal current - rounded value: 3 A

Refining: Gold

Type: H 1015 L

CS: 2.54 mm

Pitch of spring: 4.4 mm

Pin Ø: 1.37 mm

Pin length: 25.4 mm

Spring force: 1.5 N

Resistance: ≤30 mΩ

Nominal current (details): 3.0 A

RoHS-compliant: Yes

Product type: Precision test tip sleeve

Description

Test jacks Series 1015. Spring contacts for assembly and PCB tests. Sleeve with crimp or solder connection for Series 1015.
