RECOM LED driver 0 - 600 mA 2 - 35 V DC adjustable 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
0.6A LED Driver 'LIGHTLINE' DIP reg
- 2 - 35 V DC
- 0 - 600 mA
Technical specifications
- Product type
LED driver
- Dim
(L x W x H) 22.1 x 12.6 x 8.5 mm
- Output voltage (max.)
35 V DC
- Output voltage (min.)
2 V DC
- Max. output current
600 mA
- Output current (max.) - rounded
600 mA
- LED driver features
adjustable
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
0 mA
- Input voltage (max.)
36 V
- Min. input voltage
4.50 V
- Width
12.6 mm
- Height
8.5 mm
- Length
22.1 mm
Documents & Downloads
Datasheet
Datasheet 2337740 RECOM LED driver 0 - 600 mA 2 - 35 V DC adjustable 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2337740 RECOM LED driver 0 - 600 mA 2 - 35 V DC adjustable 1 pc(s)
Warranty Terms
Warranty Terms 2337740 RECOM LED driver 0 - 600 mA 2 - 35 V DC adjustable 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
