RECOM LED driver 12 W 500 mA 2 - 24 V DC 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
12W AC/DC LED power supply 'LIGHTLINE' 3.75kV reg
- 2 - 24 V DC
- 500 mA
Technical specifications
- Product type
LED driver
- Dim
(L x W x H) 128 x 50 x 13 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
2 V DC
- Max. output current
500 mA
- Output current (max.) - rounded
500 mA
- Max. power
12 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
264 V
- Min. input voltage
198 V
- Power range
12 W (max)
- Width
50 mm
- Height
13 mm
- Length
128 mm
Documents & Downloads
Datasheet
Datasheet 2337915 RECOM LED driver 12 W 500 mA 2 - 24 V DC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2337915 RECOM LED driver 12 W 500 mA 2 - 24 V DC 1 pc(s)
Warranty Terms
Warranty Terms 2337915 RECOM LED driver 12 W 500 mA 2 - 24 V DC 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
