RECOM LED driver 22 W 700 mA 2 - 31 V DC 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
20W AC/DC LED power supply 'LIGHTLINE' 3.75kV reg
- 2 - 31 V DC
- 700 mA
Technical specifications
- Product type
LED driver
- Dim
(L x W x H) 128 x 50 x 13 mm
- Output voltage (max.)
31 V DC
- Output voltage (min.)
2 V DC
- Max. output current
700 mA
- Output current (max.) - rounded
700 mA
- Max. power
22 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
264 V
- Min. input voltage
198 V
- Power range
22 W (max)
- Width
50 mm
- Height
13 mm
- Length
128 mm
Documents & Downloads
Datasheet
Datasheet 2337889 RECOM LED driver 22 W 700 mA 2 - 31 V DC 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2337889 RECOM LED driver 22 W 700 mA 2 - 31 V DC 1 pc(s)
Warranty Terms
Warranty Terms 2337889 RECOM LED driver 22 W 700 mA 2 - 31 V DC 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
