RECOM R15C2T25/R-CT DC/DC converter 0.100 A 2.5 W Content 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Brand.2514 R15C2T25/R DC/DC converter single Ou
- DC-OK-signal, remote function, remote sense, output voltage can be programmed
Technical specifications
- INSULATION VOLTAGE I/P-O/P 5000 V
- SSOP casing
- Product type
DC/DC converter
- Type
R15C2T25/R-CT
- Min. input voltage
13.5 V
- Input voltage (max.)
15 V
- Max. output current
0.100 A
- Output current (max.) - rounded
100 mA
- Efficiency (max.)
45 %
2.5 W
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+150 °C
- Dim
(L x W x H) 12.83 x 7.5 x 3.55 mm
- Height
3.55 mm
- Length
12.83 mm
- Width
7.5 mm
- Output voltage (max.)
22.5 V
- Output voltage (min.)
2.5 V
- Output current (min.)
-0.012 A
- Content
1 pc(s)
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3435828 RECOM R15C2T25/R-CT DC/DC converter 0.100 A 2.5 W Content 1 pc(s)
Description
The R15C2T25/R insulated DC/DC converter with 2.5 W is a versatile solution for isolated gate bias voltages, especially for transistors such as IGBTs, Si- and SiC MOSFETs and cascade goose. This compact converter has a wide input voltage range of 13.5 - 18VDC and programmable asymmetric output voltages that ensure precise control and performance optimization for power electronics applications. With high 5kVAC/1min insulation, 1.4kVDC operating voltage, high CMTI value of 150kV/μs and remarkable stability up to 125°C (0.5W), it offers superior reliability even in harsh high-performance and high-frequency switching environments. The extremely low insulation capacitance of less than 3.5pF ensures minimum noise propagation over the insulation barrier. All these extraordinary properties are housed in a compact SMD form factor of 7.5 x 12.83 mm, WAS makes it an ideal choice for all requirements of insulated gate pretensions.
