RECOM RACM600-24SL/OF SMPSU 24 V 25 A 600 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
RECOM RACM600-L SNT U-bracket single out
- Output 24 V / 25 A
- Power 600 W
- Screw terminal
Technical specifications
- Features: Peak power, remote function, remote sense, DC-OK-signal, output voltage adjustable, AUX-power supply, DC compatible
- Efficiency 93 %
- Application: ITE, Industry, Medicine
- Short circuit protection 1
- Overvoltage protection 1
- Short circuit protection 1
- Overvoltage protection 1
- Insulation voltage 4,000 V
- Housing: Open frame
- Input Current
- Switch-on current max. 30 A.
- Protection class: II
- Leakage current 0.3 mA
- Product type
SMPSU
- Input voltage (max.)
300 V DC
275 V AC
- Max. output current
25 A
- Output current (max.) - rounded
25 A
- Min. input voltage
120 V DC
80 V AC
- Dim
(L x W x H) 196.80 x 101.60 x 40.60 mm
- Output voltage (max.)
24 V
- Connection
Screw terminal
600 W
- No. of outputs
1 x
- Type
open
- Operating temperature (max.)
+70 °C
- Operating temperature (min.)
-20 °C
- Width
101.60 mm
- Height
40.60 mm
- Length
196.80 mm
- Type
RACM600-24SL/OF
- MTBF
500000 h
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 2887540 RECOM RACM600-24SL/OF SMPSU 24 V 25 A 600 W
User & Safety Instructions
User & Safety Instructions 2887540 RECOM RACM600-24SL/OF SMPSU 24 V 25 A 600 W
Warranty Terms
Warranty Terms 2887540 RECOM RACM600-24SL/OF SMPSU 24 V 25 A 600 W
Description
Hints
These power supplies are intended for installation in terminals.
