RECOM RP-0512D DC/DC converter 5 V -12 V, 12 V -0.042 A 1 W No. of outputs: 2 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Capacitive load max. 220 µF
- Remaining ripple 100 MVP-p
- Application: Medicine, ITE, Industry
- Casing: SIP7
- Input voltage ratio 1:1
- Product type
DC/DC converter
- Type
RP-0512D
- Nominal voltage
5 V
- Min. input voltage
4.5 V DC
- Input voltage (max.)
5.5 V DC
- No. of outputs
2 x
- Output voltages
-12 V
12 V
- Max. output current
-0.042 A
- Efficiency (max.)
82 %
1 W
- Insulation voltage
5.200 V
- Connection
THT
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+85 °C
- Dim
(L x W x H) 19.65 x 7.05 x 10.20 mm
- Height
10.20 mm
- Length
19.65 mm
- Width
7.05 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
