RECOM RPMGH12-40 DC/DC converter (print) 12 V 40 A 480 W Content 1 pc(s)

Green printed circuit board with four copper coils and a sticker labelled 'RECOM RPMH-10 series', showing electronic components.

Green printed circuit board with four copper coils and a sticker labelled 'RECOM RPMH-10 series', showing electronic components.

Image similar

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

1/2 brick housing

Product type: DC/DC converter (print)

Type: RPMGH12-40

Min. input voltage: 18 V DC

Input voltage (max.): 75 V DC

Output voltages: 12 V

Max. output current: 40 A

Output current (max.) - rounded: 40 A

: 480 W

Connection: THT

Operating temperature (min.): -40 °C

Operating temperature (max.): +120 °C

Dim: (L x W x H) 57.9 x 61 x 15 mm

Height: 15 mm

Length: 57.9 mm

Width: 61 mm

RoHS-compliant: Yes

Output voltage (max.): 24 V

Output voltage (min.): 8 V

Weight: 49 g

Content: 1 pc(s)

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

Datasheet

Datasheet 3313866 RECOM RPMGH12-40 DC/DC converter (print) 12 V 40 A 480 W Content 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3313866 RECOM RPMGH12-40 DC/DC converter (print) 12 V 40 A 480 W Content 1 pc(s)

Warranty Terms

Warranty Terms 3313866 RECOM RPMGH12-40 DC/DC converter (print) 12 V 40 A 480 W Content 1 pc(s)

What kind of DC/DC Converters are you looking for?
