RECOM RSH2-2412S/H3 DC/DC converter 24 V 12 V 0.167 A 2 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Capacitive load max. 820 µF
- Remaining ripple 50 MVP-p
- Application: ITE, Industry
- Casing: DIP14
- Input voltage ratio 2:1
- Product type
DC/DC converter
- Type
RSH2-2412S/H3
- Nominal voltage
24 V
- Min. input voltage
18 V DC
- Input voltage (max.)
36 V DC
- No. of outputs
1 x
- Output voltages
12 V
- Max. output current
0.167 A
- Output current (max.) - rounded
167 mA
- Efficiency (max.)
82 %
2 W
- Insulation voltage
3.000 V
- Connection
SMD
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+100 °C
- Dim
(L x W x H) 18.90 x 17.20 x 8.70 mm
- Height
8.70 mm
- Length
18.90 mm
- Width
17.20 mm
- RoHS-compliant
Yes
- Content
1 pc(s)
