RICHWELL Ceramic capacitor Radial lead 0.047 nF 1000 V DC 5 % (Ø x H) 7.5 mm x 3.5 mm 1 pc(s)
Part number:
Item no:
Product type
Ceramic capacitor
Type
Radial lead
Nominal voltage
1000 V DC
Capacity (elec.)
0.047 nF
Content
1 pc(s)
Datasheet (PDF)
Highlights & Details
Richwell Ko 47pF 1KV RM5 5% CH
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series: TCH3A
- Design_1: Radial
- Ceramic type: NPO
- Technology: Ceramic disc capacitor
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Disk thickness 3.5 mm
- 7.5 mm disc diameter
- Wire diameter 0.6 mm.
- Pitch_1:5.08 mm
- Capacitance 0.047 nF
- Capacity_1: 0.047
- Capacitance unit: NF
- Capacity Tolerance 5%
- Nominal voltage DC 1,000 V
- Product type
Ceramic capacitor
- Type
Radial lead
- Nominal voltage
1000 V DC
- Capacity (elec.)
0.047 nF
- Tolerance ±
5 %
- Content
1 pc(s)
- Height
3.5 mm
- (Ø)
7.5 mm
- CS
5.08 mm
- Dim
(Ø x H) 7.5 mm x 3.5 mm
- Dielectric
C0G
- Material
Ceramic
- RoHS-compliant
Yes
- Type
TCH3A470J07L526N
Documents & Downloads
Datasheet
Datasheet 3463937 RICHWELL Ceramic capacitor Radial lead 0.047 nF 1000 V DC 5 % (Ø x H) 7.5 mm x 3.5 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463937 RICHWELL Ceramic capacitor Radial lead 0.047 nF 1000 V DC 5 % (Ø x H) 7.5 mm x 3.5 mm 1 pc(s)
Description
RICHWell single-layer capacitor
