Buy Rigol DP932E Bench PSU (adjustable voltage) 0 - 30 0 - 3 A 198 W USB , LAN remote controlled No. of outputs 3 x

A digital laboratory power supply with three display indicators, showing voltages of 30.00V, 0.00V and 6.00V along with their corresponding current strengths.

Datasheet (PDF)

Fast track dispatch on Mon, 5 Oct

1 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 419.33 / piece)

€ 419.33

plus VAT.

Only 1 Piece(s) available

14-day return policy included

Report legal concerns

Highlights & Details

Programmable linear DC power supply for e-commerce, 198 watts, 3 channels

No. of outputs 3 x
0 - 30 / 0 - 3 A
0 - 30 V DC / 0 - 3 A
0 V DC - 6 V / 0 - 3 A
198 W
USB , LAN
remote controlled

Technical specifications

Type: DP932E

Product type: Bench PSU (adjustable voltage)

No. of outputs: 3 x

: 198 W

Technology: Linear regulated PSU

Interfaces: USB
LAN

Features: remote controlled

Dim: (L x W x H) 419 x 239 x 157 mm

: Manufacturer's standards (no certificate)

Weight: 9.150 g

Output voltage (max.): 30 V DC

Output voltage (min.): 0 V DC

Output voltage 2 (max.): 30 V DC

Output voltage 2 (min.): 0 V DC

Output voltage 3 (max.): 6 V

Output voltage 3 (min.): 0 V DC

Max. output current: 3 A

Output current (min.): 0 A

Output current 2 (max.): 3 A

Output current 2 (min.): 0 A

Output current 3 (max.): 3 A

Output current 3 (min.): 0 A

Width: 239 mm

Height: 157 mm

Length: 419 mm

UKCA: yes

Compliance & Certifications

Certified by EU Garan

Documents & Downloads

Datasheet

Datasheet 2624377 Rigol DP932E Bench PSU (adjustable voltage) 0 - 30 0 - 3 A 198 W USB , LAN remote controlled No. of outputs 3 x

User & Safety Instructions

User & Safety Instructions 2624377 Rigol DP932E Bench PSU (adjustable voltage) 0 - 30 0 - 3 A 198 W USB , LAN remote controlled No. of outputs 3 x

Warranty Terms

Warranty Terms 2624377 Rigol DP932E Bench PSU (adjustable voltage) 0 - 30 0 - 3 A 198 W USB , LAN remote controlled No. of outputs 3 x

Description

The laboratory power supply DP932E is a 198 W, 3 channel linear DC power supply, with very low noise and isolated channels.

This text is machine translated.

Features

3 independantly adjustable channels with 32V/3A, 32V/3A and 6V/5A (10A, optional)10.92 cm (4.3-inch) LCD color touch screenHigh resolution for measurementsAbility to measure and display large dynamic current ranges
