Rittal SK 3361.640 Cooler 400 V 0.51 kW (W x H x D) 280 x 550 x 280 mm Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Cooler
Operating voltage
400 V
Power
0.51 kW
Width
280 mm
Number
Total (€ 3,407.56 / piece)
€ 3,407.56
plus VAT.
14-day return policy included
Technical specifications
- Material: Stainless steel 1.4301 (AISI 304)
- Net weight: 25.568 kg
- Gross weight: 26.675 kg
- Dimensions: Width 280 mm
- Height: 550 mm
- Depth: 280 mm
- Benefit: Network-enabled with the IoT interface via Blue e IoT adapter for cooling devices starting with 500 W cooling power with e-Comfort controller
- Colour RAL 9007
- Design: Wall-mounting
- Air flow (free-blowing): External circuit: 480 m³/h.
- Internal circuit: 600 m³/h.
- Rated operating voltage 400 V, 2~, 50 Hz/60 Hz
- Temperature control: E-Comfort controller (factory setting +35 °C)
- Operating temperature range -10°C...55°C.
- Refrigerant/Coolant: Refrigerant: R-513A
- Quantity: 0.28 kg
- Global Warming Potential (GWP): 631
- CO2 equivalent (CODOS e): 0.18 t
- Rated power Pel: Rated power L35 L35/50 Hz: 0.42 kW
- Rated power L35 L35/60 Hz: 0.46 kW
- Rated power L35 L50/50 Hz: 0.48 kW
- Rated power L35 L50/60 Hz: 0.51 kW
- Rated current max.: At 50 Hz: 1.2 A
- At 60 Hz 1.4 A
- Starting current (max.): At 50 Hz: 3.1 A
- At 60 Hz 3.3 A
- Total cooling power according to DIN EN 14511: Cooling power L35 L35/50 Hz: 0.82 kW
- Cooling performance L35 L35/60 Hz: 0.82 kW
- Cooling performance L35 L50/50 Hz: 0.59 kW
- Cooling performance L35 L50/60 Hz: 0.6 kW
- Energy efficiency ratio (EER) 50/60 Hz L35 L35: Cooling rate L35 L35 (EER) 50 Hz: 1.95
- Cooling power L35 L35 (EER) 60 Hz: 1.78
- Protection class IP according to EN 60 529: External circuit IP 34
- Internal circuit IP 54
- Storage temperature range -40°C...70°C.
- Setting range 20 °C...52 °C
- Permissible operating pressure (p max.): 28 bar
- Fuse: Transformer circuit breaker: 6.3...10 A
- Operating temperature max at 60 Hz: 52 °C.
- Depth of transformer 65 mm
- Diameter transformer 126 mm
- Protection class NEMA UL type 12
- Packaging type
Piece
- Product type
Cooler
- Type
SK 3361.640
- Features
Fan
- Operating voltage
400 V
- Max. current consumption
3.3 A
0.51 kW
- Air flow rate
480 m³/h
600 m³/h
- Compatible with
Rittal
- Factory colour
Grey-aluminium (RAL 9007)
- Min. temperature
+10 °C
- Max. temperature
+55 °C
IP34
IP54
- Width
280 mm
- Height
550 mm
- Depth
280 mm
- Dim
(W x H x D) 280 x 550 x 280 mm
- Weight
25.568 kg
- Content
1 pc(s)
280
Other
550 mm
280 mm
AC
FALSE
TRUE
FALSE
10-55 °C
360-440 V
360-440 V
750 W
FALSE
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3386791 Rittal SK 3361.640 Cooler 400 V 0.51 kW (W x H x D) 280 x 550 x 280 mm Piece 1 pc(s)
Description
SK Blue e cooler, wall mount, 0.82 kW, 400 V, 2~, 50/60 Hz, stainless steel, BHT 280 x 550 x 280 mm
Energy-efficient blue e wall-mounted coolers in the power classes 300 W to 4000 W and starting from 1000 W with integrated electrical condensation. Available in the special formats "across" and "flat".
This text is machine translated.
Energy-efficient blue e wall-mounted coolers in the power classes 300 W to 4000 W and starting from 1000 W with integrated electrical condensation. Available in the special formats "across" and "flat".
This text is machine translated.
