Rittal SK 3383.640 Cooler 400 V 0.65 kW (W x H x D) 597 x 417 x 475 mm 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cooler
Operating voltage
400 V
Power
0.65 kW
Width
597 mm
Height
417 mm
Sales and shipping:
Total (€ 2,856.30 / piece)
€
Technical specifications
- Material: Stainless steel 1.4301 (AISI 304)
- Net weight: 46 kg
- Gross weight: 47 kg
- Dimensions: Width 597 mm
- Height: 417 mm
- Depth: 475 mm
- Benefit: Network-enabled with the IoT interface via Blue e IoT adapter for cooling devices starting with 500 W cooling power with e-Comfort controller
- Colour RAL 9007
- Design: Roof structure
- Air flow (free-blowing): External circuit: 1,600 m³/h.
- Internal circuit: 491 m³/h.
- Rated operating voltage 400 V, 2~, 50 Hz/60 Hz
- Temperature control: E-Comfort controller (factory setting +35 °C)
- Operating temperature range -10°C...55°C.
- Refrigerant/Coolant: Refrigerant: R-513A
- Quantity: 0.65 kg
- Global Warming Potential (GWP): 631
- CO2 equivalent (CODOS e): 0.41 t
- Rated power Pel: Rated power L35 L35/50 Hz: 0.42 kW
- Rated power L35 L35/60 Hz: 0.56 kW
- Rated power L35 L50/50 Hz: 0.48 kW
- Rated power L35 L50/60 Hz: 0.65 kW
- Rated current max.: At 50 Hz: 1.7 A
- At 60 Hz 2.2 A
- Starting current (max.): At 50 Hz: 4.6 A
- At 60 Hz 5.7 A
- Total cooling power according to DIN EN 14511: Cooling power L35 L35/50 Hz: 1 kW
- Cooling performance L35 L35/60 Hz: 1.09 kW
- Cooling performance L35 L50/50 Hz: 0.8 kW
- Cooling performance L35 L50/60 Hz: 0.81 kW
- Energy efficiency ratio (EER) 50/60 Hz L35 L35: Cooling rate L35 L35 (EER) 50 Hz: 2.4
- Cooling power L35 L35 (EER) 60 Hz: 1.95
- Protection class IP according to EN 60 529: External circuit IP 34
- Internal circuit IP 54
- Storage temperature range -40°C...70°C.
- Setting range 20 °C...53 °C
- Permissible operating pressure (p max.): 28 bar
- Fuse: Transformer circuit breaker: 6.3...10 A
- Operating temperature max at 60 Hz: 53 °C.
- Connection type (electrical): Plug-in terminal block
- Duty cycle:100%
- Product type
Cooler
- Type
SK 3383.640
- Operating voltage
400 V
- Max. current consumption
5.7 A
0.65 kW
- Air flow rate
1600 m³/h
491 m³/h
- Factory colour
Grey-aluminium (RAL 9007)
- Min. temperature
+10 °C
- Max. temperature
+55 °C
IP34
IP54
- Connection
Plug & Clip
- Width
597 mm
- Height
417 mm
- Depth
475 mm
- Dim
(W x H x D) 597 x 417 x 475 mm
- Weight
46 kg
- Content
1 pc(s)
597
Other
417 mm
475 mm
AC
FALSE
TRUE
TRUE
10-55 °C
360-440 V
360-440 V
1000 W
FALSE
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3386787 Rittal SK 3383.640 Cooler 400 V 0.65 kW (W x H x D) 597 x 417 x 475 mm 1 pc(s)
Description
SK Cooling device Blue e, roof structure, 1 kW, 400 V, 2~, 50/60 Hz, stainless steel, BHT 597 x 417 x 475 mm
Energy-efficient Blue e roof-mounted cooling devices in the power classes 500 W to 4,000 W with standard integrated e-comfort controller and electrical condensation.
This text is machine translated.
Energy-efficient Blue e roof-mounted cooling devices in the power classes 500 W to 4,000 W with standard integrated e-comfort controller and electrical condensation.
