Buy RO/SE LM-Heizungen Enclosure fan heater HHS160 220 - 240 V AC 160 W (L x W x H) 150 x 125 x 70 mm (without holder) 1 pc(

A metallic heatsink with a fan, used for cooling electronic components. The manufacturer's name and technical details are visible on the side.

A wind turbine generator with three rotor blades and generator housing on a tall mast.

1/2

Datasheet (PDF)

Sales and shipping:

Number

Piece(s)

Total (€ 130.24 / piece)

€

Report legal concerns

Highlights & Details

RO/SE LM-Heizungen Enclosure fan heater HHS160 220 - 240 V AC 160 W (L x W x H) 150 x 125 x 70 mm (without holder) 1 pc(s)

Technical specifications

Fan flow rate: 160 m3/h

Type: HHS160

Connection: Connector

Features: Thermostat

Min. operating voltage: 220 V AC

Max. operating voltage: 240 V AC

Operating voltage: 220 - 240 V AC

: 160 W

Length: 150 mm

Width: 125 mm

Height: 70 mm

Dim. (add. text): without holder

Dim: (L x W x H) 150 x 125 x 70 mm (without holder)

: 160 W

Type: HHS160

Fitting method: (screw) bracket

Connection: 4-pin Phoenix Contact^®connector

Operating voltage: 220 - 240 V AC

Product type: Enclosure fan heater

Documents & Downloads

Datasheet

Datasheet 185520 RO/SE LM-Heizungen Enclosure fan heater HHS160 220 - 240 V AC 160 W (L x W x H) 150 x 125 x 70 mm (without holder) 1 pc(

User & Safety Instructions

User & Safety Instructions 185520 RO/SE LM-Heizungen Enclosure fan heater HHS160 220 - 240 V AC 160 W (L x W x H) 150 x 125 x 70 mm (without holder) 1 pc(

Description

Especially for the panel builder developed high-performance heating. Easy assembly by screw fixing. Horizontal and vertical applications. Guards also above the heating element. To adjust the fan heater is the thermostat type "TH-H" under the Order No. 18 58 88 recommended.
