Robotis Adapter MBS-Z-57
EAN:
Part number:
Item no:
Number
Total (€ 40.33 / piece)
€ 40.33
plus VAT.
14-day return policy included
Technical specifications
- Dimensions 48 x 57 mm
- Supply voltage 7.4 - 24 V
- Max. current 10 A
- Product type
Adapter
- Length
57 mm
- Width
48 mm
- Manufacturer part #
MBS-Z-57
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3089914 Robotis Adapter MBS-Z-57
Description
The U2D2 Power hub board combines the versatile connection Diverser power supplies with the ROBOTIS U2D2 adapter. The Power hub board is equipped with the connector system of the DYNAMIXEL X-series and enables the connection of TTL & RS485 servo motors in the same way. In addition, the U2D2 adapter can also be attached to the 48 x 57 mm Power board, which reduces the risk of malfunction caused by pulling the connection cables.
This text is machine translated.
This text is machine translated.
Features
- U2D2 support
- DYNAMIXEL X Series Connector Systems (TTL & RS485)
- Power supply by means of screw terminals or SMPS power supply
Scope of delivery
- U2D2 Power hub
- Rivets
- M3 nuts
