Image similar

Technical drawing of a door handle with dimensions: Length 120 mm, Depth 22 mm, Hole spacing 50 mm. Side and front view.

1/2

Image similar

Product type

Rotary mechanism

Compatible with (details)

3KF size 3

Factory colour

Grey

Dim

(L x W x H) 300 x 98 x 144 mm

Type

Rotary handle mechanism

Datasheet (PDF)

Siemens

Dispatches on Wed, 14 Oct

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 163.86 / piece)

€ 163.86

plus VAT.

14-day return policy included

Report legal concerns

Technical specifications

IP65 rating
Door locking system design: Door locking
Net weight: 997 g

Product type: Rotary mechanism

Compatible with (details): 3KF size 3

Factory colour: Grey

Dim: (L x W x H) 300 x 98 x 144 mm

Type: Rotary handle mechanism

Width: 98 mm

Height: 144 mm

Length: 300 mm

Depth: 450 mm

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 1738131 Rotary mechanism Grey Siemens 8UD11614AE21

User & Safety Instructions

User & Safety Instructions 1738131 Rotary mechanism Grey Siemens 8UD11614AE21

Description

Handle with masking frame Emergency switching-off Size 75x 75, for shaft 8x 8, I-0-II, Handle size 55 mm Accessory for 3KC0 size 1 and 2
