Safety relay P2HZ X1P 24VDC 3n/o 1n/c 2so PILZ Operating voltage: 24 V DC 3 makers, 1 breaker (W x H x D) 45 x 94 x 121
EAN:
Part number:
Item no:
Product type
Safety relay
Connector
Screw terminals
Operating voltage
24 V DC
Type
P2HZ X1P 24VDC 3n/o 1n/c 2so
Contact type
3 makers
1 breaker
Datasheet (PDF)
Technical specifications
- Application possibilities: Two-hand monitoring type III C.
- Terminal type: Pluggable
- Operating modes: Two-channel, cross-circuit detection
- STANDARDS: EN 574 TYPE III C, EN 62061, EN ISO 13849-1, VDE 0113-1
- Number of safety contacts without delay: 3
- Stop Category: 0
- Product type
Safety relay
- Type
P2HZ X1P 24VDC 3n/o 1n/c 2so
- Connector
Screw terminals
- Operating voltage
24 V DC
- Contact type
3 makers
1 breaker
- Switching voltage (max.)
240 V AC
- Switching current (max.)
1.5 A
- Operating temperature (min.)
-25 °C
- Operating temperature (max.)
+55 °C
- Depth
121 mm
- Width
45 mm
- Height
94 mm
- Dim
(W x H x D) 45 x 94 x 121 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2182919 Safety relay P2HZ X1P 24VDC 3n/o 1n/c 2so PILZ Operating voltage: 24 V DC 3 makers, 1 breaker (W x H x D) 45 x 94 x 121
User & Safety Instructions
User & Safety Instructions 2182919 Safety relay P2HZ X1P 24VDC 3n/o 1n/c 2so PILZ Operating voltage: 24 V DC 3 makers, 1 breaker (W x H x D) 45 x 94 x 121
Description
The safety switching devices of the PNOZ X product family ensure safe monitoring of two-handed buttons. Two variants are available: Type IIIC and type IIIA according to EN 574.
