Safety relay PNOZ e1p C 24VDC 2so PILZ Operating voltage: 24 V DC 2 makers (W x H x D) 22.5 x 94 x 121 mm Incl. shock ab
EAN:
Part number:
Item no:
Product type
Safety relay
Connector
Spring force connector
Operating voltage
24 V DC
Type
PNOZ e1p C 24VDC 2so
Contact type
2 makers
Datasheet (PDF)
Technical specifications
- Applications: Emergency stop monitoring without delay, limit switches, light barrier monitoring Typ.2 m T, light barrier overw. Typ.2 o T, light barrier overw. Type.4, Protective door monitor
- Terminal type: Pluggable
- Operating modes: Single-channel, automatic start, two-channel, cross-circuit detection, start-up testing, manual start with monitoring, without cross-circuit detection, self-test
- STANDARDS: DIN V VDE 801-1/A1, EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1, VDE 0116
- Product standard EN 60947-5-1
- Stop Category: 0
- Safety outputs 2 ST
- Number of clock outputs: 2
- Product type
Safety relay
- Type
PNOZ e1p C 24VDC 2so
- Connector
Spring force connector
- Operating voltage
24 V DC
- Contact type
2 makers
- Features
Incl. shock absorber
IP54
- Operating temperature (min.)
-10 °C
- Operating temperature (max.)
+55 °C
- Depth
121 mm
- Width
22.5 mm
- Height
94 mm
- Dim
(W x H x D) 22.5 x 94 x 121 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2182932 Safety relay PNOZ e1p C 24VDC 2so PILZ Operating voltage: 24 V DC 2 makers (W x H x D) 22.5 x 94 x 121 mm Incl. shock ab
User & Safety Instructions
User & Safety Instructions 2182932 Safety relay PNOZ e1p C 24VDC 2so PILZ Operating voltage: 24 V DC 2 makers (W x H x D) 22.5 x 94 x 121 mm Incl. shock ab
Description
The PNOZelog product family combines the experience of electromechanical safety switching devices with the advantages of modern electronics. With PNOZelog you can reliably monitor one to four safety functions. Wear-free, safety and long service life guarantee you economical use. Save wiring! PNOZelog can be easily linked by logical operators. Increase the availability of your machine with advanced diagnostics. Power-on, self-testing and runtime testing also ensure maximum safety.
Benefit from the shock and vibration-resistant safety relay PNOZelog. Especially when used in mobile applications with large vibrations. Maintenance-free and long life are guaranteed by the use of modern electronics.
The advantages of the PNOZelog safety relay at a glance
· less wiring effort due to simple logical links (AND/OR)
· high availability due to extended diagnostics
· maintenance-free due to consistent use of semiconductor technology
· no malfunction due to welding, soiling, bouncing or burning of contacts
· highest safety through permanent self-test; Error detection is not coupled to the on and off cycle
· Long life even with frequent switching operations or cyclic functions
· Safe switching operations even with the smallest loads
· Fast commissioning without aids through plug-in terminals with spring force and screw connection
This text is machine translated.
Benefit from the shock and vibration-resistant safety relay PNOZelog. Especially when used in mobile applications with large vibrations. Maintenance-free and long life are guaranteed by the use of modern electronics.
The advantages of the PNOZelog safety relay at a glance
· less wiring effort due to simple logical links (AND/OR)
· high availability due to extended diagnostics
· maintenance-free due to consistent use of semiconductor technology
· no malfunction due to welding, soiling, bouncing or burning of contacts
· highest safety through permanent self-test; Error detection is not coupled to the on and off cycle
· Long life even with frequent switching operations or cyclic functions
· Safe switching operations even with the smallest loads
· Fast commissioning without aids through plug-in terminals with spring force and screw connection
This text is machine translated.
