Safety relay PNOZ XV2 3/24VDC 2n/o 2n/o t PILZ Operating voltage: 24 V DC 2 makers (W x H x D) 45 x 87 x 121 mm 1 pc(s)
EAN:
Part number:
Item no:
Product type
Safety relay
Connector
Screw terminals
Operating voltage
24 V DC
Type
PNOZ XV2 3/24VDC 2n/o 2n/o t
Contact type
2 makers
Datasheet (PDF)
Technical specifications
- Application possibilities: Emergency stop monitoring without delay, limit switch, protective door monitor, emergency stop monitoring delayed
- Terminal type: Fixed
- Operating modes: Single-channel, automatic start, two-channel, cross-circuit detection, manual start with overw
- Standards: EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1
- Number of safety contacts undelayed: 2
- Number of safety contacts delayed: 2
- Product standard: EN 60947
- -
- 1: En 60947-1; semiconductor outputs: 0-1. Current at AC15: 5.0 A
- safety contact Delay type: Fall-back delay
- adjustable times: 0.10 s, 0.20 s, 0.30 s, 0.40 s, 0.50 s, 0.60 s, 0.70 s, 0.80 s, 1.00 s, 1.50 s, 2.00 s, 3.00 s.
- Product type
Safety relay
- Type
PNOZ XV2 3/24VDC 2n/o 2n/o t
- Connector
Screw terminals
- Operating voltage
24 V DC
- Contact type
2 makers
- Switching voltage (max.)
240 V AC
- Switching current (max.)
7.0 A
- Operating temperature (min.)
-10 °C
- Operating temperature (max.)
+55 °C
- Depth
121 mm
- Width
45 mm
- Height
87 mm
- Dim
(W x H x D) 45 x 87 x 121 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2182889 Safety relay PNOZ XV2 3/24VDC 2n/o 2n/o t PILZ Operating voltage: 24 V DC 2 makers (W x H x D) 45 x 87 x 121 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2182889 Safety relay PNOZ XV2 3/24VDC 2n/o 2n/o t PILZ Operating voltage: 24 V DC 2 makers (W x H x D) 45 x 87 x 121 mm 1 pc(s)
Description
Our safety switching devices PNOZ X have proven their reliability and robustness. They are used in a wide range of applications and in a wide variety of safety applications. You use a PNOZ X for each safety function. The technical basis here are potential-free, electromechanical contacts in the 2-relay technology. The sizes vary from 22.5 to 90 mm, the number of contacts from two to eight. Whatever your security requirements, PNOZ X has already proven itself millions of times in the tough industrial environment.
