Schabus 300219 Water leak detector mains-powered
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 70.58 / piece)
€ 70.58
plus VAT.
Only 2 Piece(s) available
Highlights & Details
Water detector SHT 228
- Visual alert
- Simple installation (230 V socket output)
- Also suitable for other liquids (e.g. heating oil, diesel, vegetable oil, lubricating oils, etc.)
- Connected device is activated when an alarm is issued
- Continuous adjustment of the follow-up time from 0 to 100 s.
- Float switch with 2.5 m cable (extendable)
Technical specifications
- Product type
Water leak detector
- Mounting type
Wall
- Operating voltage
230 V
- Power supply (LOV)
mains-powered
- Width
57 mm
- Height
232 mm
- Depth
38 mm
- Dim
(W x H x D) 57 x 232 x 38 mm
- Function
Water leak detector
Documents & Downloads
Datasheet
Datasheet 1405683 Schabus 300219 Water leak detector mains-powered
User & Safety Instructions
User & Safety Instructions 1405683 Schabus 300219 Water leak detector mains-powered
Description
The water detector SHT 228 is a ready to plug pump control system which, when it reaches a certain water level a connected water pump on and after a specified time also switches off. Via a continuously variable adjustment wheel is the follow-up time of the pump from 0 to 100 seconds. An audible and visual warning signals the change of the water level.
The robust float switch is particularly suitable for dirty water or other liquids (e.g. fuel oil, diesel, vegetable oil, lubricating oil, etc.).
The switching contact of the float closes from approx. 4 cm level high and activates the input of the water sensor. By turning the float body, one gets the reverse switching function.
Extension sensor cable:
If required, you can change the sensor cable up to 50 m with a cable (2 x 0.5 mm²) extend. You must re-connect the existing sensor cable cut and terminals.
This text is machine translated.
The robust float switch is particularly suitable for dirty water or other liquids (e.g. fuel oil, diesel, vegetable oil, lubricating oil, etc.).
The switching contact of the float closes from approx. 4 cm level high and activates the input of the water sensor. By turning the float body, one gets the reverse switching function.
Extension sensor cable:
If required, you can change the sensor cable up to 50 m with a cable (2 x 0.5 mm²) extend. You must re-connect the existing sensor cable cut and terminals.
This text is machine translated.
Scope of delivery
- Water detector SHT 228
- Mounting material (screws + dowel)
