Schalk GSR209 Limit switch 1 pc(s)
EAN:
Part number:
Item no:
Product type
Limit switch
Type
GSR209
Dim
(W x H) 18 mm x 88 mm
Output (current)
10 A
Operating voltage
207 - 253 V
Datasheet (PDF)
Technical specifications
- Type
GSR209
- Product type
Limit switch
- Dim
(W x H) 18 mm x 88 mm
- Output (current)
10 A
- Operating voltage
207 - 253 V
- Max. operating voltage
253 V
- Min. operating voltage
207 V
- Content
1 pc(s)
- Width
18 mm
- Height
88 mm
- Supply voltage (num.)
230 V
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3818825 Schalk GSR209 Limit switch 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3818825 Schalk GSR209 Limit switch 1 pc(s)
Description
The limit monitors GSR 2 and GSF 2 are versatile and still simple to use. The GSR 2 is used in connection with the sensor SR 1 for the rain signal. The connected sensor is supplied with a potential-free extra-low voltage (PELV) directly through the limit switch. The use of an additional power supply is thus not necessary.
This text is machine translated.
