Schlegel QRUV EPO switch round IP65, IP67, IP69K 2 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Lighting: no.
- Writable: no.
- Front frame: Yellow
- Shape: Round
- Switching function: Latching function
- Operating temperature: -30°C ... 70°C.
- Enabling function: no.
- Storage temperature: -50°C ... 85°C
- Tamper-proof: Yes
- Anti-blocking collar: no.
- Switch position indicator: Yes
- Unlocking: Clockwise and anti-clockwise rotation
- STANDARDS: EN 60947-5-1, EN 60947-5-5, EN ISO 13850
- Product type
EPO switch
- Switch/button features
round
- Unlocking mechanism
Turn
- Print motif
Blank
- Lighting type
None
- Factory colour
Red
- Connection
External contact
- Recess diameter
22.3 mm
- Functions
latch
- Durability
50000
- Length
60.9 mm
- Width
32 mm
- Height
32 mm
- Min. temperature
-50 °C
- Max. temperature
85 °C
IP65
IP67
IP69K
- Compatible with (details)
QUARTEX®-R.
- Type
QRUV
- Content
2 pc(s)
- Dim
(L x W x H) 60.9 x 32 x 32 mm
- RoHS-compliant
Yes
Documents & Downloads
Datasheet
Datasheet 2238385 Schlegel QRUV EPO switch round IP65, IP67, IP69K 2 pc(s)
