Schneider Electric A9F90376 A9F90376 Circuit breaker

Circuit breaker Acti 9 C120H, 15kA (IEC/EN 60898-1), 15kA (IEC/EN 60947-2). 2-pin, rated current 63A, B characteristic, operating voltage (Ue) 380-415V AC, insulation voltage (UI) 500V AC. Protection of circuits against short-circuit currents and overload currents. terminals IP20. Fully open contacts are indicated by the OFF mark on the gear knob so that work on the downstream part can be carried out with the appropriate level of safety. Supply from top and bottom. Jumber switching for low wear switching of the contacts. Technology of the triggering unit- thermo-magnetic. Combined with the FI Block Vigi for C120. Additional attachable help modules (optional) - display of switching position, error triggering, work-current release, undervoltage release, over-voltage release. Colour tone RAL 9003. The C120H line circuit breaker fulfills the following standards-IEC/EN 60898-1 and IEC/EN 60947-2. Furthermore, this series is VDE certified.

This text is machine translated.
