Schneider Electric C103TM100 C103TM100 Electronics module
EAN:
Part number:
Item no:
Product type
Electronics module
Number of pins
3
Content
1 pc(s)
Rated permanent current Iu
100 A
Number of poles
3.0
Datasheet (PDF)
Number
Total (€ 109.24 / piece)
€ 109.24
plus VAT.
14-day return policy included
Technical specifications
- Product type
Electronics module
- Number of pins
3
- Content
1 pc(s)
100 A
3.0
Undelayed
FALSE
800
800
Thermal/magnetic release
AC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2935112 Schneider Electric C103TM100 C103TM100 Electronics module
Datasheet 2935112 Schneider Electric C103TM100 C103TM100 Electronics module
User & Safety Instructions
User & Safety Instructions 2935112 Schneider Electric C103TM100 C103TM100 Electronics module
User & Safety Instructions 2935112 Schneider Electric C103TM100 C103TM100 Electronics module
Description
The TM100D is a 3p 3D thermal-magnetic tripping unit used in the Compact NSX 100/160/250 circuit breakers. This thermo-magnetic trigger device with a nominal power of 100 A is the optimum choice for all distribution applications. It has an adjustable thermal overload protection and a fixed magnetic protection against short-circuits. This product is part of our EcoStruxure Power architecture, provided it is combined with the PowerTag NSX and Compact NSX Basic Switch.
