Schneider Electric C10F3TM025 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
EAN:
Part number:
Item no:
Product type
Circuit breaker
Packaging type
Piece
Type
C10F3TM025
No. of pins
3-pin
Switching voltage (max.)
690 V AC
Datasheet (PDF)
Number
Total (€ 239.50 / piece)
€ 239.50
plus VAT.
14-day return policy included
Technical specifications
- Packaging type
Piece
- Product type
Circuit breaker
- Type
C10F3TM025
- No. of pins
3-pin
- Switching voltage (max.)
690 V AC
- OCR type
TM
- Content
1 pc(s)
0
0
25 A
3
0
IP30
Front side
FALSE
Screw connection
Rocker lever
FALSE
36 kA
FALSE
FALSE
TRUE
Built-in device fixed built-in technique
FALSE
TRUE
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2927510 Schneider Electric C10F3TM025 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
Datasheet 2927510 Schneider Electric C10F3TM025 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
User & Safety Instructions
User & Safety Instructions 2927510 Schneider Electric C10F3TM025 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
User & Safety Instructions 2927510 Schneider Electric C10F3TM025 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
Information
Information 2927510 Schneider Electric C10F3TM025 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
Description
The NSX100F is a complete fixed-mount 3P 3D circuit breaker designed to optimize space requirements and breaking capacity. It is an optimum choice for all standard and special applications. The breaking capacity (ICU) is 36 kA eff. At 415 VAC, 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product has a thermo-magnetic triggering device (TMD) with a rated power of 25 A. The tripping device TMD offers an adjustable thermal overload protection and a fixed magnetic protection. This 3-pole version (105 mm x 161 mm x 86 mm) comes with a variety of optional functions and accessories. It complies with international standards (IEC 60947), CCC, EAC and Marine specifications. Compact NSX100F is part of Schneider Electric's EcoStruxure power architecture.
