Schneider Electric C10N3MA050 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
EAN:
Part number:
Item no:
Product type
Circuit breaker
Packaging type
Piece
Type
C10N3MA050
No. of pins
3-pin
Switching voltage (max.)
690 V AC
Datasheet (PDF)
Number
Total (€ 281.51 / piece)
€ 281.51
plus VAT.
14-day return policy included
Technical specifications
- Packaging type
Piece
- Product type
Circuit breaker
- Type
C10N3MA050
- No. of pins
3-pin
- Switching voltage (max.)
690 V AC
- Content
1 pc(s)
105
161 mm
86 mm
FALSE
50 A
FALSE
3.0
IP40
FALSE
Screw connection
Other
Magnetic
50 kA
FALSE
Built-in device fixed built-in technique
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2927533 Schneider Electric C10N3MA050 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
Datasheet 2927533 Schneider Electric C10N3MA050 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
User & Safety Instructions
User & Safety Instructions 2927533 Schneider Electric C10N3MA050 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
Information
Information 2927533 Schneider Electric C10N3MA050 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC Piece
Description
The NSX100N is a complete fixed 3P 3D circuit breaker designed to optimize space requirements and breaking capacity. It is an optimal choice for motor protection applications. The breaking capacity (ICU) is 50 kA eff. At 415 VAC, 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product has a magnetic release device (MA) with a rated power of 50 A. The tripping device MA offers an adjustable magnetic protection for instantaneous triggering. This 3-pole version (105 mm x 161 mm x 86 mm) comes with a variety of optional functions and accessories. It complies with international standards (IEC 60947), CCC, EAC and Marine specifications. Compact NSX100N is part of Schneider Electric's EcoStruxure power architecture.
