Schneider Electric C10N3TM040 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 105 x 161 x 86 mm S
EAN:
Part number:
Item no:
Product type
Circuit breaker
Packaging type
Single
Type
C10N3TM040
No. of pins
3-pin
Switching voltage (max.)
690 V AC
Datasheet (PDF)
Number
Total (€ 273.11 / piece)
€ 273.11
plus VAT.
14-day return policy included
Technical specifications
- Packaging type
Single
- Product type
Circuit breaker
- Type
C10N3TM040
- No. of pins
3-pin
- Switching voltage (max.)
690 V AC
- Mounting type
Fixed
- OCR type
TM
- Depth
86 mm
- Width
105 mm
- Height
161 mm
- Dim
(W x H x D) 105 x 161 x 86 mm
- Content
1 pc(s)
0
0
40 A
3
0
IP30
Front side
FALSE
Screw connection
Rocker lever
FALSE
50 kA
FALSE
FALSE
TRUE
Built-in device fixed built-in technique
FALSE
TRUE
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2927556 Schneider Electric C10N3TM040 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 105 x 161 x 86 mm S
Datasheet 2927556 Schneider Electric C10N3TM040 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 105 x 161 x 86 mm S
User & Safety Instructions
User & Safety Instructions 2927556 Schneider Electric C10N3TM040 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 105 x 161 x 86 mm S
Information
Information 2927556 Schneider Electric C10N3TM040 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 105 x 161 x 86 mm S
Description
The NSX100N is a complete fixed 3P 3D circuit breaker designed to optimize space requirements and breaking capacity. It is an optimum choice for all standard and special applications. The breaking capacity (ICU) is 50 kA eff. At 415 VAC, 50/60 Hz. The operating voltage is 690 VAC 50/60 Hz. This product has a thermo-magnetic triggering device (TMD) with a rated power of 40 A. The tripping device TMD offers an adjustable thermal overload protection and a fixed magnetic protection. This 3-pole version (105 mm x 161 mm x 86 mm) comes with a variety of optional functions and accessories. It complies with international standards (IEC 60947), CCC, EAC and Marine specifications. Compact NSX100N is part of Schneider Electric's EcoStruxure power architecture.
