Schneider Electric C11B3TM100B Circuit breaker 1 pc(s) (W x H x D) 81 x 137 x 80 mm
EAN:
Part number:
Item no:
Product type
Circuit breaker
Type
C11B3TM100B
No. of pins
3-pin
Mounting type
DIN rail
Depth
80 mm
Datasheet (PDF)
Number
Total (€ 231.09 / piece)
€ 231.09
plus VAT.
14-day return policy included
Technical specifications
- Product type
Circuit breaker
- Type
C11B3TM100B
- No. of pins
3-pin
- Mounting type
DIN rail
- Depth
80 mm
- Width
81 mm
- Height
137 mm
- Dim
(W x H x D) 81 x 137 x 80 mm
- Content
1 pc(s)
0
0
100 A
3
0
IP40
Front side
FALSE
Screw connection
Toggle
TRUE
25 kA
TRUE
FALSE
FALSE
Built-in device fixed built-in technique
FALSE
TRUE
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2927628 Schneider Electric C11B3TM100B Circuit breaker 1 pc(s) (W x H x D) 81 x 137 x 80 mm
Datasheet 2927628 Schneider Electric C11B3TM100B Circuit breaker 1 pc(s) (W x H x D) 81 x 137 x 80 mm
User & Safety Instructions
User & Safety Instructions 2927628 Schneider Electric C11B3TM100B Circuit breaker 1 pc(s) (W x H x D) 81 x 137 x 80 mm
Description
It is a compact circuit breaker Compact NSXm, 100 A, 25 kA at 415 VAC, for all standard NS applications. It offers new features such as Everlink technology, DIN rail and panel mounting capability. It integrates new spring-type attachments, which are visible externally. Compact NSXm is one of the smallest compact circuit breakers available on the market, 81 mm (W) x 137 mm (H) x 80 mm (D). This is a 3-pin design with integrated thermo-magnetic triggering device. It ensures compliance with international standards (IEC 60947/CCC/EAC) and marine specifications.
