Schneider Electric LC1DT60A3P7 Electrical contactor + auxiliary contact Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
Electrical contactor
No. of pins
4-pin
Connection
Spring-loaded connector
Packaging type
Piece
Type
LC1DT60A3P7
Technical specifications
- Packaging type
Piece
- Product type
Electrical contactor
- Type
LC1DT60A3P7
- No. of pins
4-pin
- Control voltage (max.)
230 V AC
- Control voltage range
230 V AC (max)
- Permanent current (max.)
60 A
- Features
+ auxiliary contact
- Mounting type
DIN rail
- Connection
Spring-loaded connector
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1979606 Schneider Electric LC1DT60A3P7 Electrical contactor + auxiliary contact Piece 1 pc(s)
Description
4-pin TeSys D power contactor for applications up to 60A/AC1, spring-loaded terminals. 230V 50/60Hz AC coil, built-in auxiliary contacts 1S+1NC, thanks to its certified S-mirror contact, can be used in safety applications. Compact, DIN rail mounting, thus high reliability and long life. Multi-standard certified (IEC, UL, CSA, CCC, EAC, Marine) and Green Premium compliant (RoHS/Reach).
This text is machine translated.
This text is machine translated.
