Schneider Electric LC1G330LSEA Electrical contactor + auxiliary contact 1 pc(s)
EAN:
Part number:
Item no:
Product type
Electrical contactor
No. of pins
3-pin
Type
LC1G330LSEA
Auxiliary contact type
1 maker
Switching voltage (max.)
400 V AC
Datasheet (PDF)
Number
Total (€ 1,298.32 / piece)
€ 1,298.32
plus VAT.
14-day return policy included
Technical specifications
- Product type
Electrical contactor
- Type
LC1G330LSEA
- No. of pins
3-pin
- Auxiliary contact type
1 maker
- Switching voltage (max.)
400 V AC
- Permanent current (max.)
330 A
- Features
+ auxiliary contact
- Max. temperature
60 °C
- Content
1 pc(s)
FALSE
160.0 kW
3
0
1
1
330.0 A
440.0 A
Bolt connection
AC/DC
330 A
160.0 kW
250
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2935989 Schneider Electric LC1G330LSEA Electrical contactor + auxiliary contact 1 pc(s)
Datasheet 2935989 Schneider Electric LC1G330LSEA Electrical contactor + auxiliary contact 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2935989 Schneider Electric LC1G330LSEA Electrical contactor + auxiliary contact 1 pc(s)
Information
Information 2935989 Schneider Electric LC1G330LSEA Electrical contactor + auxiliary contact 1 pc(s)
Description
TeSys control - Giga contactor, 3 pole (3S) for safe switching of motors with AC-3 up to 330A / 200kW at 400V. The contactor has an AC/DC wide-range coil of 200-500V with low energy consumption plus two control inputs 24 V DC. Included in the delivery is a mounted auxiliary switch block with a normally open and a normally closed contact. Designed for demanding applications with maximum operating rates of up to 600 cycles per hour and environments up to 60°C. High reliability and long life with a mechanical lifetime of 5 Mcycles. Green Premium-conform (RoHS/REACH).
