Schneider Electric LC1K1210B7 Electrical contactor 3 makers 5.5 kW Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
Electrical contactor
No. of pins
3-pin
Power
5.5 kW
Connection
Screw terminal
Packaging type
Piece
Datasheet (PDF)
Number
Total (€ 38.65 / piece)
€ 38.65
plus VAT.
Only 10 Piece(s) available
Highlights & Details
Power contactor, 3p+1S, 5.5kW/400V/AC3, 12A, coil 24V 50/60Hz
- TeSys K contactor 3 pole (3 NO contact)
- For motor control applications up to 12 A/690 V AC-3 (5.5 kW at 400 V)
- For inductive load control applications up to 20 A/690 V AC-1
- 24 V 50/60 Hz AC coil
- Built-in 1-NO auxiliary contact
- Connection via screw terminals
- For operating rates up to 600 cycles/hour and environments up to 50 °C.
Technical specifications
- Packaging type
Piece
- Product type
Electrical contactor
- Type
LC1K1210B7
- No. of pins
3-pin
- Contact type
3 makers
- Auxiliary contact type
1 maker
- Control voltage (max.)
24 V AC
- Control voltage range
24 V AC (max)
- Switching voltage (max.)
690 V AC
- Permanent current (max.)
20 A
5.5 kW
- Connection
Screw terminal
- Max. temperature
50 °C
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1980104 Schneider Electric LC1K1210B7 Electrical contactor 3 makers 5.5 kW Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1980104 Schneider Electric LC1K1210B7 Electrical contactor 3 makers 5.5 kW Piece 1 pc(s)
Description
TeSys K 3-pole contactor (3 NO contact) for motor control applications up to 12 A/690 V AC-3 (5.5 kW at 400 V) and for inductive load control applications up to 20 A/690 V AC-1. It has a 24 V 50/60 Hz AC coil, an integrated 1 NO auxiliary contact and connection via screw terminals. For operating rates up to 600 cycles/hour and environments up to 50 °C, it offers reliability and durability for standard applications.
