Schneider Electric LVS04174 Busbar 1400 mm 4 pc(s)
EAN:
Part number:
Item no:
Product type
Busbar
Length
1400 mm
Width
32 mm
Height
8 mm
Dim
(L x W x H) 1400 x 32 x 8 mm
Datasheet (PDF)
Number
Total (1 m = € 84.78)
€ 474.79
plus VAT.
14-day return policy included
Technical specifications
- Rated current In:630 A.
- Product type
Busbar
- Length
1400 mm
- Width
32 mm
- Height
8 mm
- Dim
(L x W x H) 1400 x 32 x 8 mm
- Content
4 pc(s)
- Type
LVS04174
Documents & Downloads
Datasheet
Datasheet 3209092 Schneider Electric LVS04174 Busbar 1400 mm 4 pc(s)
Datasheet 3209092 Schneider Electric LVS04174 Busbar 1400 mm 4 pc(s)
User & Safety Instructions
User & Safety Instructions 3209092 Schneider Electric LVS04174 Busbar 1400 mm 4 pc(s)
Information
Information 3209092 Schneider Electric LVS04174 Busbar 1400 mm 4 pc(s)
Information 3209092 Schneider Electric LVS04174 Busbar 1400 mm 4 pc(s)
Information 3209092 Schneider Electric LVS04174 Busbar 1400 mm 4 pc(s)
Information 3209092 Schneider Electric LVS04174 Busbar 1400 mm 4 pc(s)
Description
PrismaSet P. Linergy BS 4-pin, rear-side vertical copper busbar for 400 A with a rail size of 32 x 8 mm, with threaded holes M6 at 25 mm intervals, with a rated surge resistance (Ipk) 77 kA. Rated insulation voltage (UI) 1000 V AC, rated short-time current (ICC) 150 kA. Or 4-pole multi-stage vertical copper busbar for 630 A with a rail size of 32 x 8 mm, with threaded holes M6 at 25 mm intervals. With a rated surge current (Ipk) 55 kA, rated insulation voltage (UI) 750 V AC, rated short-time current (ICC) 150 kA, and a length of 1400 mm.
