Schneider Electric MTN663529 Rail mounted PSU (DIN) DC/DC 24 V 1 A 24 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 96.63 / piece)
€ 96.63
plus VAT.
14-day return policy included
Technical specifications
- Nominal input voltage
230 V/AC
- Product type
Rail mounted PSU (DIN) DC/DC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
24 W
- Output type (power supply units)
Fixed voltage
- Output voltage (nominal)
24 V
- No. of outputs
1 x
- Dim
(L x W x H) 66.5 x 87.5 x 93 mm
- Weight
0.796 kg
- Manufacturer part #
MTN663529
- Content
1 pc(s)
- Width
87.5 mm
- Height
93 mm
- Length
66.5 mm
- Type
MTN663529
87.5
93 mm
66.5 mm
66.5 mm
TRUE
FALSE
AC
24 W
FALSE
Screw connection
FALSE
FALSE
FALSE
IP20
FALSE
FALSE
FALSE
None
1 A
None
1
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2913412 Schneider Electric MTN663529 Rail mounted PSU (DIN) DC/DC 24 V 1 A 24 W No. of outputs:1 x Content 1 pc(s)
Datasheet 2913412 Schneider Electric MTN663529 Rail mounted PSU (DIN) DC/DC 24 V 1 A 24 W No. of outputs:1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2913412 Schneider Electric MTN663529 Rail mounted PSU (DIN) DC/DC 24 V 1 A 24 W No. of outputs:1 x Content 1 pc(s)
User & Safety Instructions 2913412 Schneider Electric MTN663529 Rail mounted PSU (DIN) DC/DC 24 V 1 A 24 W No. of outputs:1 x Content 1 pc(s)
Information
Information 2913412 Schneider Electric MTN663529 Rail mounted PSU (DIN) DC/DC 24 V 1 A 24 W No. of outputs:1 x Content 1 pc(s)
Information 2913412 Schneider Electric MTN663529 Rail mounted PSU (DIN) DC/DC 24 V 1 A 24 W No. of outputs:1 x Content 1 pc(s)
Information 2913412 Schneider Electric MTN663529 Rail mounted PSU (DIN) DC/DC 24 V 1 A 24 W No. of outputs:1 x Content 1 pc(s)
Description
Schneider Electric KNX Power supply for 24 V binary inputs, weather station REG-K/4-way, analogue input module REG/4-way, rain sensor, wind sensor with 0-10 V interface and heating, KNX/IP Router REG-K. With fuse. For mounting on TH35 DIN rail as per EN 60715. Supply primary AC 230 V, +/- 10%, 50-60 Hz. Output voltage AC 24 V. Output current max. 1 A. Fuse 5x20mm, 250 V, T 160 mA. Device width of 5 TE corresponds to approx. 90 mm. Supplied with spare fuse. Colour light-gray.
