Schneider Electric Servo motor SH32053P02F2200 94.4 Nm
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Starting torque ratio: 0
- Starting current ratio 0
- Number of phases: 3
- Shaft end design: Other
- Design: Other
- Load cycle: Other
- Rated frequency 50-60 Hz
- Rated voltage: 230 V
- Operating temperature 0-40 °C
- Suitable for frequency control: No.
- Intrinsic safety (IS): Without
- Insulation class IEC: Other
- Breakdown torque ratio: 0
- Cooling method: Other
- Storage: Other
- With condensation protection: No.
- With positive temperature coefficient resistor (PTC): No.
- With resistance thermometer detector (RTD): No.
- Motor energy efficiency class: Other
- Voltage type AC/DC
- Vacuum pressure impregnation (VPI): Other
- Housing material: Other
- Overload capability: No.
- Holding torque
94.4 Nm
- Manufacturer part #
SH32053P02F2200
- Type
SH32053P02F2200
- Flange size
205 mm
IP65/67
- Type
Three-phase synchronous motor
- Nominal voltage
230 V
- Phases
3
- Nominal power
5.5 kW
- Number of pins
0
- Nominal torque
94.4 Nm
- Max. ambient temperature
40 °C
- Min. ambient temperature
0 °C
Rotary current synchronous motor
AC/DC
230 V
3
Other
0
Other
50-60 Hz
0-40 °C
Other
Other
0
0
0
FALSE
FALSE
None
FALSE
Other
Other
Other
Other
FALSE
Other
Other
FALSE
- UKCA
yes
- Product type
Servo motor
Documents & Downloads
Datasheet
Datasheet 3763489 Schneider Electric Servo motor SH32053P02F2200 94.4 Nm
User & Safety Instructions
User & Safety Instructions 3763489 Schneider Electric Servo motor SH32053P02F2200 94.4 Nm
Description
Lexium SH3 servomotor for motion-based automation with PacDrive 3. This range of AC servomotors has a low rotor moment of inertia which enables a high acceleration capability for dynamic applications. Owing to the winding technology, a higher power density results in a compact design This servo has a flange dimension of 205 mm and a motor length of 3 stacks. Its winding is optimized for torque and speed. It has a continuous standstill torque of 94.4 Nm and a peak torque of 330 Nm. The voltage-dependent rated speed reaches 2000 rpm with a nominal power of up to 5.5 kW. The shaft end is designed as a smooth shaft. The absolute optical encoder is designed as a sine/cos multiturn with high resolution of 128 periods per revolution, corresponding to WAS 131,072 points per rotation. A holding brake is integrated. The motor cable is connected via an angled M40 plug and the encoder cable via an angled M23 plug to the corresponding Lexium 62 servo drives. The degree of protection of the shaft is IP65 and the housing IP67.
