Schneider Electric SSR SSD1A320BDC2 20 A Switching voltage (max.): 600 V AC Zero crossing 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
SSR
Control voltage (min.)
4 V DC
Control voltage (max.)
32 V DC
Switching voltage (max.)
600 V AC
Datasheet (PDF)
Number
Total (€ 43.69 / piece)
€ 43.69
plus VAT.
14-day return policy included
Technical specifications
- Packaging type
Piece
- Product type
SSR
- Type
SSD1A320BDC2
- Switching type
Zero crossing
- Connection
Screw terminal
- Control voltage (min.)
4 V DC
- Control voltage (max.)
32 V DC
- Control voltage range
4 - 32 V DC
- Switching voltage (min.)
48 V AC
- Switching voltage (max.)
600 V AC
- Current load (max.)
20 A
- Output voltage (min.)
48 V AC
- Output voltage (max.)
600 V AC
- Max. output current
20 A
- Content
1 pc(s)
1
TRUE
0 A
0 A
DC
0 A
0 A
0 A
TRUE
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2922370 Schneider Electric SSR SSD1A320BDC2 20 A Switching voltage (max.): 600 V AC Zero crossing 1 pc(s)
Datasheet 2922370 Schneider Electric SSR SSD1A320BDC2 20 A Switching voltage (max.): 600 V AC Zero crossing 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2922370 Schneider Electric SSR SSD1A320BDC2 20 A Switching voltage (max.): 600 V AC Zero crossing 1 pc(s)
Information
Information 2922370 Schneider Electric SSR SSD1A320BDC2 20 A Switching voltage (max.): 600 V AC Zero crossing 1 pc(s)
Description
Solid state relays SSD of the Harmony series. Suitable for mounting on a DIN rail. The load circuit is designed for 1-phase networks in the range of 48-600V AC and it can be switched 20 A. Control voltage is at 4-32 VDC. The switching behavior is zero-voltage switching. The connection is made with screw terminals. Approvals CE, UL, CSA, EAC, RoHS, IEC 61373, IEC 60947-4-3.
