Name: Schneider Electric VBD1 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 60 x 74 x 121 mm Piece
Brand: Schneider Electric
SKU: 2375004

Rotary switch with positions '0' for off and 'I' for on. Black housing with white handle, screw terminals at the top.

Image similar

Product type

Circuit breaker

Connection

Screw terminal

Packaging type

Piece

Type

VBD1

Current load

21.8 A

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Design: Lockable
Operating type: Rotary drive
Locking with turning handle: 1 to 3 padlocks 4…8 mm
Conventional thermal current 32 A.
Mechanical life: 100000 cycles
Dimensions of handle front panel: 60 x 60 mm
PVC-free: Yes
Halogen-free: Yes

Packaging type: Piece

Product type: Circuit breaker

Type: VBD1

Current load: 21.8 A

No. of pins: 3-pin

Switching voltage (max.): 690 V AC

Mounting type: Fixed

Min. temperature: -20 °C

Max. temperature: +50 °C

Connection: Screw terminal

: IP20
IP65

Depth: 121 mm

Width: 60 mm

Height: 74 mm

Dim: (W x H x D) 60 x 74 x 121 mm

Content: 1 pc(s)

UKCA: yes
