Schnepp Jack plug set Plug, straight, Socket, straight Pin diameter: 2 mm Red, Black 4 Parts
EAN:
Part number:
Item no:
Product type
Jack plug set
Connector type
Plug, straight
Socket, straight
Pin Ø
2 mm
Connection
Soldering
Nominal current
10 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 5.45
5
6% = € 0.32
€ 5.13
Volume discounts vary depending on the seller
You save € 0.00
Number (Package size 4 Parts)
Total (€ 5.45 / piece)
€ 9.24
-41 %
€ 5.45
plus VAT.
14-day return policy included
Highlights & Details
Schnepp Jack plug set Plug, straight, Socket, straight Pin diameter: 2 mm Red, Black 4 Parts
- 10 A Red, Black
Our service for you
Technical specifications
- Product type
Jack plug set
- Connector type
Plug, straight
Socket, straight
- Pin Ø
2 mm
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Cross section (flexible) (max.)
1.5 mm²
- Connection
Soldering
- Factory colour
Red
Black
- Insulation type
Partially insulated
- Manufacturer part #
SET
- Type
SET
- Dim
(Ø) 2 mm
- Type
2 mm
- Content
4 Parts
- Insulation material
PE
- Contact material
Gold plated
- (Ø)
2 mm
- RoHS-compliant
Yes
- Nominal current (details)
10 A
- Connection
Soldering
Documents & Downloads
Datasheet
Datasheet 730998 Schnepp Jack plug set Plug, straight, Socket, straight Pin diameter: 2 mm Red, Black 4 Parts
Description
Gold-plated plug contacts · Usable up to wire Ø 1.5 mm ² max. cable outer diameter 3 mm, solder, loading capacity max. 10A (depending on the connected cable).
Scope of delivery
- 2 plugs, 2 sockets, each with red and black grips.
