Schnepp N 4041 L Banana plug Plug, straight Pin diameter: 4 mm Grey 1 pc(s)
EAN:
Part number:
Item no:
Product type
Banana plug
Connector type
Plug, straight
Pin Ø
4 mm
Connection
Soldering
Nominal current
30 A
Datasheet (PDF)
136 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.09
10
8% = € 0.16
€ 1.93
25
11% = € 0.22
€ 1.87
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.09 / piece)
€
Highlights & Details
Schnepp N 4041 L Banana plug Plug, straight Pin diameter: 4 mm Grey 1 pc(s)
- 4 mm
Technical specifications
- Product type
Banana plug
- Connector type
Plug, straight
- Pin Ø
4 mm
- Nominal current
30 A
- Nominal current - rounded value
30 A
- Cross section (flexible) (max.)
2.5 mm²
- Connection
Soldering
- Factory colour
Grey
- Insulation type
Partially insulated
- Manufacturer part #
N 4041 L-GY
- Type
N 4041 L
- Dim
(Ø) 4 mm
- Scoop-proof
Yes
- Content
1 pc(s)
- Insulation material
PE
- Contact material
Brass nickel plated
- (Ø)
4 mm
- RoHS-compliant
Yes
- Resistance
3 MΩ
- Nominal current (details)
30 A
- Connection
Soldering
- Cable diameter
2.5 mm²
Documents & Downloads
Datasheet
Datasheet 731366 Schnepp N 4041 L Banana plug Plug, straight Pin diameter: 4 mm Grey 1 pc(s)
Datasheet 731366 Schnepp N 4041 L Banana plug Plug, straight Pin diameter: 4 mm Grey 1 pc(s)
User & Safety Instructions
User & Safety Instructions 731366 Schnepp N 4041 L Banana plug Plug, straight Pin diameter: 4 mm Grey 1 pc(s)
Description
Straight cable outlet · Accidental contact protection · Temperature range: -20 - +80°C.
Hints
Without protective cover
